Specifications
Equipped With
Specifications:
Height of Centers.....................9"
Distance between centers..............45"
Swing over bed........................18 1"
Swing over saddle wings...............17"
Swing over cross Slide................9.13"
Cross slide travel....................10.6"
Tool section max......................1"
Coolant tank capacity.................13 gal.
Width of Bed..........................13.4"
Height of Bed.........................12.4"
Spindle Nose (Camlock)................D1-6
Spindle through hole..................2.36"
Spindle taper.........................MT#6
Taper in reduction sleeve.............MT#4
Spindle dia at front bearing..........3.35"
Number of bearings....................2
Bearing class (radial round)..........Normal
Spindle speed range (RPM).............80-850, 250-2500
Tailstock Quill travel................6"
- Quill diameter.....................2.56"
- Quill taper hole...................MT#4
Spindle Motor HP......................10
Power requirements, control...........110V; 1P; 10A
Power requirements, machine...........220V;3P;60Hz
Amps full load current................33
Dimensions net........................94" x 52" x 73"
Dimensions shipping...................91" x 52" x 84"
Weight net............................3285 lbs.
Weight shipping.......................3800 lbs.
Maximum rapid feed X..................100
Maximum rapid feed Z..................250
Coolant pump motor....................1/8 HP
Spindle motor brake...................Dynamic braking
Way surface hardness..................480 - 560 HB
Head stock lubrication................Oil bath
Equipped with:
Prototrak SLX Control
